Cross-sectional drawings
Lesson details
Learning outcome
I can produce cross-sectional drawings to show internal details.
Key learning points
- Cross-sectional drawings help see inside objects by cutting them open on paper.
- Cross-sectional drawings are used when important details are hidden inside and can't be seen from the outside.
- A cutting plane is a dashed line with arrows that shows where the object is cut to reveal the inside.
- Hatching indicates a cut section, showing internal details and clarifying it's not the full design.
Keywords
Cross-section - an internal view of a 3D object when cut through a plane
Cutting plane - indicates where a sectional view is taken from, represented by a dashed line with arrows
Internal details - the features inside an object only visible in a cross-sectional drawing.
Common misconception
A cross-sectional drawing is just another drawing view, such as front or side.
A cross-sectional view is an internal view showing what the inside looks like when sliced through. It is is meant to reveal hidden details inside an object.
Teacher tip
Having objects that can be cut/opened to show internal details will help pupils visualise the concept.
Equipment
Pencil, rubber, ruler.
Licence
Lesson video
Loading...
Prior knowledge starter quiz
6 Questions
Q1.What is an orthographic projection?
Q2.Which of these views would you NOT usually see in an orthographic projection?
Q3.How are hidden lines or details represented in an orthographic projection?
Q4.When creating an orthographic projection, which view do you draw first?
Q5.What view is this?
Q6.Which term describes the size and shape of an object?
Assessment exit quiz
4 Questions
Q1.What type of drawing shows internal features of an object?
Q2.What can cross-sectional drawings help us to understand?
Q3.In which fields are cross-sectional drawings commonly used?
Q4.What do hatched marks on a cross-sectional drawing indicate?
